Dreno DNA 65-2/110 T EX 400V Manual Submersible Pump
Dreno DNA Submersible Pumps are used for the transfer of sewage and waste water. The pumps are fitted with a wide channel impeller that permits the free passage of solids rendering it particularly useful in water treatment plants, domestic, municipal and farming applications. The 4 pole version can be used in applications where continuous S1 service is needed and are characterised by their quiet operation.
The pumps are manufactured from GG20 Cast Iron with a double back to back mechanical seal and oil chamber.
Upper Mechanical seal: CA/CE/Viton
Lower Mechanical Seal: SIC/SIC/Viton
Upper Bearing: Single raw ball bearing
Lower Bearing: Single raw ball bearing
IP Protection: IP68
Motor protection: not present
Humidity sensor: not present
ATEX: not present
Applied Paint: Two component water-based paint
Cable Length [m]: 10
Lubricating Oil: Q8 WF15
Oil Quantity [Kg]: 0.24
Pump: Cast Iron EN 1561 EN-GJL-200
Impeller: Cast iron EN 1561 EN-GJL-200
Motor shaft: Stainless steel AISI 420
Cooling Jacket: Not available
Screw: Stainless steel A2-70
Cable: H07RN8F
Pumped Liquid: Sewage
Density [Kg/dm³]: 1.1
pH: 6-10
Temperature Range: 0-40°C
